Our XING series NextGen motors have become popular after the initial
release in 2018 and became the new standard on the market. Was it the curved
shape or the internal damping ring to protect the bearing, or was it the higher
quality NSK bearings coupled with a higher grade titanium alloy shaft? We've
been copied and compared all these years, but now it's time to set a new
standard again! We're finally ready to announce our predecessor the XING2!



The smooth, reliable and powerful XING motors were upgraded and we achieved
an even higher standard in our manufactory as well as better performance than
ever before. New center slotted N52H curved arc magnets were introduced to
drastically reduce response time of the motor! Maybe the biggest bottleneck of
our FPV flight controller is the motor due to it's translation delay of it
braking and accelerating. XING2 motors offer faster response to translate your
PID loop quicker and get that locked-in feeling you were always looking
for!



Due to the high quality materials used and the durable joint of bell and
shaft, we were able to reduce the magnet air gap and stator lamination to a
minimum. The smaller the air gap is, the lower that reluctance and the higher
the magnetic flux (which is the magnetic analog of current) causing more
efficiency and higher power!



Early 2018 we started to put o-rings on the top of our bearings between
motor bell and stator. This acts as an absorber if your bell or shaft has gone
through crashing and keeps the bearing gap tight to reduce all those vibrations
induced by high rpms! It can also reduce the axial impact force just enough to
keep your bearings smooth and quiet. All our experience, high quality 7075
bells, O-ring bearing protection and all the other features you've just seen on
your original XING series are still inbuilt in a new shape and design!



Features:



5mm titanium alloy shaft, our strongest prop shaft ever!

Crash resistant 7075 aluminum bell

Smooth and long-lasting NSK 9x4x4 bearings

Center slotted N52H curved arc magnets

XING O-ring bearing gap protection

Motor wires protector

Dynamically balanced



Specification



Model: XING2 2207

Version: CW Screw Thread

Input Voltage: 4S/6S Lipo

Configuration: 12N14P

Dimension: φ29*19.25mm

Stator Length: 5mm

Weight: 34g with short wire

Wire length: 20AWG 160mm

Mounting pattern: 16*16 φ3mm
